We believe you will find our Silver Hawk race trailers to be the best-built car haulers on the market today. Aside from our outstanding list of standard equipment (which others consider additionally priced options) our interiors and exteriors are engineered for safety, rugged durability and great looks. Stop, Shop and Compare. With American Hauler, you are sure to be a winner before you ever start the race!
And, as always, our trailers are made with pride in the USA!
Standard Features, Specifications and Available Options subject to change without notice.
Gallery
| Model Number | SIL8520T3 | SIL8524T3 | SIL8528T4 | SIL8532R4 |
| Body Length | 20'0" | 24'0" | 28'0" | 32'0" |
| Body Width | 8'4" | 8'4" | 8'4" | 8'4" |
| Overall Length | 24'7" | 28'7" | 32'7" | 36'7" |
| Overall Width | 8' 6" | 8' 6" | 8' 6" | 8' 6' |
| Overall Height (to top of roof vent) | 9'1" | 9'1" | 9'3" | 9'3" |
| Interior Length | 19'8" | 23'8" | 27'8" | 31'8" |
| Interior Width | 8'1" | 8'1" | 8'1" | 8'1" |
| Interior Height | 6'10" | 6'10" | 6'10" | 6'10" |
| Side Door (WxH) | 36" x 78" | 36" x 78" | 36" x 78" | 36" x 78" |
| Rear Ramp Door (WxH) | 96" x 78" | 96" x 78" | 96" x 78" | 96" x 78" |
| Beavertail | 48" | 48" | 72" | 72" |
| Width Between Wheel Boxes | 83" | 83" | 83" | 83" |
| Hitch Weight | 10% to 15% | 10% to 15% | 10% to 15% | 10% to 15% |
| Hitch Height | 20" | 20" | 22" | 22" |
| Ball Size | 2-5/16" | 2-5/16" | 2-5/16" | 2-5/16" |
| Platform Height (at Beavertail) | 19" | 19" | 21" | 21" |
| # of Axles | Tandem | Tandem | Tandem | Triple |
| GVWR | 9,900 lbs | 9,900 lbs | 12,000 lbs | 18,000 lbs |
| Brakes | Electric | Electric | Electric | Electric |
| Tires | ST225/75R15 | ST225/75R15 | ST235/80R16 | ST235/80R16 |
| Load Range | E | E | E | E |
| Tube Main Rails | 2" x 6" | 2" x 6" | 2" x 8" | 2" x 8" |
| Floor | 3/4" PlexCore | 3/4" PlexCore | 3/4" PlexCore | 3/4" PlexCore |
| Side Walls | 3/8" PlexCore | 3/8" PlexCore | 3/8" PlexCore | 3/8" PlexCore |
| 12V Trailer Connector | 7-way | 7-way | 7-way | 7-way |
